I find a way to read aovs and render container , if I had some times I will post a create 😊

Read Octane Post

from typing import Optional import c4d SET_RENDERAOV_IN_CNT=3700 SET_RENDERAOV_INPUT_0=3740 RNDAOV_TYPE=995 RNDAOV_ENABLED=994 doc: c4d.documents.BaseDocument # The active document op: Optional[c4d.BaseObject] # The active object, None if unselected c4d.CallCommand(13957) #clear console def main() -> None: rdata = doc.GetActiveRenderData() vpost = rdata.GetFirstVideoPost() OctaneRender_ID = 1029525 octVp=None # rdata[c4d.RDATA_RENDERENGINE] = OctaneRender_ID while vpost: print(vpost) if vpost.GetName() == "Octane Renderer": octVp=vpost vpost = vpost.GetNext() if octVp: aovCnt = octVp[SET_RENDERAOV_IN_CNT] print ("--- OCTANERENDER FOUND ---") print(octVp) print ("Buffer:",octVp[1010]) print ("Color space:",octVp[1028]) print ("AOV count:",aovCnt) for i in range(0,aovCnt): aov = octVp[SET_RENDERAOV_INPUT_0+i] enabled = aov[RNDAOV_ENABLED] type = aov[RNDAOV_TYPE] print ("AOV1:",aov," type:",type," enabled:", enabled) if type==185: # cryptomatte print (" crypto_type:",aov[1821]) if type==255: #z-depth AOV print (" z-depth max:",aov[3392]," env.depth:",aov[3397]) if __name__ == '__main__': main()

@m_adam

Ah gotcha. I can only access perpetual versions. C4D 2023 was not made available for perpetual.

Anyhow, thanks for the confirmation. Will close the thread.

Got it. Thank you.

@ferdinand

Uhm. It's not as complicated as that.
I mean it is complicated per se but there are already existing solutions.
Check "Sphinx Search Extension". There are several.
Pip install it and just insert it into the conf.py file.

Also, it's not really as spicing it up per se.
I mean it is but not really.

It's just adding a sub paragraph section.
The maxon redshift documentation is already doing it.
And even if you are using sphinx implementation, it's also existing.
Blender documentation is built using sphinx.


@ferdinand

Gotcha. Thanks for the clarification.
Will close this thread now.

Thx for updating.. 2023.1 seems to be working well again

@ferdinand

Gotcha. Thanks for the clarification and the sample code. Should have probably went for the matrix transforms to begin with. I was hoping I can get away with those euler angles lol.

Closing the thread now.

@m_adam

Thanks for the confirmation. Will close the thread for now.

@m_adam

Thanks for the response. Modifying the environment varialbles works for my use case.
Closing the thread now.

Hey @kng_ito,

So the normal direction of the generated polygons was the point!

It depends a bit on what you mean by normal direction, but generally speaking, normals only play a minor role here.

Wenn all segments would always lie nicely inside a plane, it would be easy. Just compute the mean point for each segment and then come up with some cockamamie rule when you would consider two segments not being in a shell-hole relation (as I did above with 'a hole is not a hole anymore when T farther away from S than S is tall or wide').

In practice things do not always lie nicely in a plane. So, you then must first project them there, find their mean plane. So, the 'point' would be finding the mean plane / dimensionality reduction. I cooked up an small example below.

Cheers,
Ferdinand

Result (the plane gizmos are a bit buggy and sliding, did not debug this. But that is why I turn them off):

The file:
spline_hole.c4d

I see.
Thank you for the reply Manuel 🙂

Hi @InterfaceGuy, this forum is only about Cinema 4D Scripting and plugins, please reach the user support via the maxon website.

Cheers,
Maxime.

@ferdinand

Thanks for the pointers.
I'll try to look up those options.

Will close this thread now.

Hi @FSS first of all happy new year ! 🙂

And I'm glad that you found a solution however even if this is in the documentation we don't explicitly support PyCharm and only provide a dummy package to have autocompletion working with any Python instance. But C4dpy is not supported by all IDE and we can't provide any support there.

If you want to have a better IDE workflow we released a plugin for Visual Studio Code, requiring a Cinema 4D plugin and a VS Code plugin.

Finally I moved this topic to general talk as it this is nothing related to Cinema 4D API.

Cheers,
Maxime.

Btw if you install the Cinema 4D Vs Code extension, pyp extension should be added as Python.

Hey @kantronin,

Thank you for reaching out to us. I would recommend having a look at the Modeling Python Examples. They are a bit hidden, but in the Geometry section I went over the general classic API geometry model of Cinema 4D.

Regarding your core questions:

Removing points from a polygon: Without wanting to be overly pedantic, I must point out that polygons only index vertices, they do not hold them; CPolygon references with its fields a, b, c, and d the vertices of the PolygonObject it is attached to. In this sense removing points from a polygon is not possible, you can just de-index them. Cinema 4D expresses both triangles and quadrangles with the type CPolygon, i.e., as quadrangles. A triangle simply repeats its c index in its d index. I explained this in the modelling examples in more detail. Removing vertices or polygons from a PolygonObject: There is neither a PolygonObject.RemovePolygon nor aPointObject.RemovePoint if that is what you are looking for. When you want to change the vertex or polygon count of a PolygonObject, you must call PolygonObject.ResizeObject and then call PointObject.SetAllPoints() and for each (new) polygon PolygonObject.SetPolygon. The operation_extrude_polygons_s26 example covers this subject, although I go there into the opposite direction, I increase the point and polygon count rather than decreasing it.

PS: Useful might also be geometry_polygonobject_s26 because I explained there the type from scratch.

Cheers,
Ferdinand

Thank you @ferdinand !

Hello @conductor,

thank you for reaching out to us. You can certainly post a job posting here, but it should happen in the General Talk forum. It can contain everything which is not directly related to one of our APIs but loosely related to CGI or development.

The same applies to this thread of yours, I have moved it to 'General Talk' .

Cheers,
Ferdinand
