Well, I do have a loop but I just pasted the code that would, hopefully, perform the calculation. And I did tried the GetDeformCache approach, but my mistake was, in fact the cloning of the object. Thank you so much for the code, Adam.

Thanks a lot Daniel for following up here. Glad to listen that the update actually fixed it, although even on 20.030 I had no better luck to reproduce. Best, Riccardo

@s_bach Ok, Thanks.

What the customer failed to mention was that the Team Render Client he used is on the same physical machine as his main Cinema 4D. Since both share the same plugins folder, the plugins were obviously installed manually for the main Cinema 4D, and thus also available for the local Team Render Client. Case closed.

@a_block No need for apologies. I thought the bearded guy had something to do with it ... Hence the reason I posted the message again. Luckily, JIT before the easter bunny was to blame.

Hi @m_adam Thank you for your reply. It works perfectly!

Hi, good we got you going It is not wrong per se to use multiple plugin directories. Actually Cinema 4D R20 was specifically designed to have multiple ones. You just need to make sure not to have duplicate plugins in these directories. Cheers, Andreas

Hi Sebastian! Turns out my issues are two seperate, but equally self inflicted problems Inserting and activating works as expected, I am blocking the update with some custom UI stuff so I will have to find a solution for that. Calling EventAdd() in the closeEvent of the UI doesn't do anything. Is there another way to force Cinema to update everything? Killing the document not only doesn't update, but actually crashes Cinema, because I am trying to kill the document from within a callback that is reacting to MSG_DOCUMENTINFO_TYPE_LOAD. I am doing some more involved environment management and sometimes I have to close a document after loading. I have a workaround that will have to do for now. In the callback I change the document path to a string I can then look for in EVMSG_CHANGE. When I detect my string there, I can then kill the document. It's not very elegant and if anyone has a better solution I would be very happy, but otherwise consider this problem solved

Please do not delete topics once they are resolved, this topic may help other people that have the same issue. Instead, use the Q&A functionality to mark a topic as solved. Cheers, Maxime.

Hello, the Source Processor only checks for coding style violations and creates auxiliary code. It cannot check for valid C++ syntax (because C++ is quite an complex language). Coming back to the issue of return values, only the compiler can check that at compile time. And, yes, unfortunately Visual Studio and Xcode behave differently. best wishes, Sebastian

Hi mafster, thanks for reaching out us. With regard to accessing images being available in the Picture Viewer, I'm sorry to confirm that there is no PictureViewer-related classes/functions exposed in the API. This is valid for both C++ and Python API. Best, Riccardo

@stevejlv I found a workaround: the value part in the value;string Cycle option list does not have to be 0,1,2 etc. So I can give them the exact value as the string part (as long as they are int) and get the value I want the old fashioned way: [c4d.ID_USERDATA,1]

@Riccardo Thank you very much for your reply Riccardo! Yes of course you are right - modifying the c4d sdk is a bad way. I just did this to see what happens. I will take a close look to the manual you have mentionend and will review the memory handling in my code. Best regards Andi

Hello, you cannot create a Material in the main() function of a Python Generator object. The main() function of the Python Generator object defines a cache of "virtual" BaseObjects which will appear in the scene. Materials cannot be created this way. A material must be inserted into the BaseDocument. This must only happen from the main thread, typically in reaction to some user interaction. One way of doing this would be to add a user data button to your Generator. Then your user could simply press that button to create the needed materials. Pressing the button can be detected by implementing the message() function. This could look like this: def main(): # search for material mat = doc.SearchMaterial("Generator Material") if mat is None: return None # create object cube = c4d.BaseObject(c4d.Ocube) # apply material ttag = cube.MakeTag(c4d.Ttexture) ttag[c4d.TEXTURETAG_MATERIAL] = mat return cube def message(id, data): if id == c4d.MSG_DESCRIPTION_COMMAND: buttonId = data['id'] # check button ID if buttonId[1].id == 1: # create material and insert it into the host document c4d.StopAllThreads() material = c4d.Material() material.SetName("Generator Material") material[c4d.MATERIAL_COLOR_COLOR] = c4d.Vector(1,0,0) doc.InsertMaterial(material, None) c4d.EventAdd() Also, please use the Q&A system. best wishes, Sebastian

thanks solved: self.data = {'sphere_size': 15, 'extension_ratio': 1, 'extend_vector': False} kind regards

@bentraje Yeah, the second part was meant just in case you have need for a manual process. GetModelingAxis() takes multiselections of elements into account. However, I believe GetModelingAxis() works by selected mode (as you can have different selections for points, polys, and edges in parallel depending on whether the point, poly, edge, or object mode is active. So if you explicitly need the point selection and use the method in a script, you may want to switch to the point mode before using GetModelingAxis(). (Also, the actual modeling axis can be changed by the tools, so caution is in order. Personally, this is the behavior I needed, so I didn't make any big experiments.)

Together with the help from the c4dlounge.eu forum the issues is solved. The main issue was I did not read the manual good enough. "Note that Size symbolizes the axis size and not the expansion of the object itself. For planar projections, the true dimension is the two/fold of the axis length."

@Cairyn Interesting "(not just on every frame but far more often)" I guess for now I guess I'll just do it in piecemeal. Other parts in Xpresso nodes and the other python tag. Thanks for the tip on the Python nodes on the Xpresso editor. Haven't tried it. I would go for the pure Xpresso set-up but its a bit finicky to set-up such as identifying where the node sits in the xpresso editor otherwise it sits on top of each other (An automatic layout command would be nice). @m_adam Thanks for the reference!

Hi Riccardo, Thanks for the first response. My bad with not catching that it was a layer shader bug, I figured I had done something wrong with the sampling. I'll start looking into the other projection samplings. Dan
